For best prices that include local delivery and (optional) training Get a Quote today. Ask about stock delivery and let us know if you need a specific model that’s not on display.

Fluke 190-104/S ScopeMeter Test Tool

  • Four electrically isolated inputs
  • CAT III 1000 V / CAT IV 600 V safety rated
  • 100 MHz bandwidth model
  • 1.25 GS/s
  • Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details
  • Quad meter measurements via scope BNC inputs
  • Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering
  • ScopeRecord roll mode, capture waveform sample data for up to 48 hours
  • TrendPlot, trend measurement readings for up to 22 days
  • Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s)
  • IP-51 rated for dust and drip proof to withstand harsh environments
  • Isolated USB ports for memory devices and PC connectivity
  • Li-Ion battery for extended operating timespan: up to 7 hours (BP291 included standard)
  • Charge spare battery using optional external battery charger (EBC290)
  • Easy-access battery door to make it easy to swap batteries
  • A handy slot to tether and lock down the oscilloscope while unattended using a standard Kensington lock
Category: Tags: , , ,

Fluke 190-104/S 20 years of ScopeMeter Test Tool Innovation

As the first four-channel portable scope safety rated CAT III 1000 V / CAT IV 600 V, the Fluke ScopeMeter 190-104/S combines an unprecedented level of performance, ruggedness, and portability with 100 MHz bandwidth and real-time sampling rates up to 1.25 GS/s and 200 ps resolution to capture noise and other disturbances. This model features deep memory up to 10,000 samples per channel; so you can examine very small parts of the waveform in detail, and it is IP-51 rated to withstand dust, drips, humidity, and wide temperature variations. Fluke ScopeMeter test tools are hand-held battery operated, designed to meet the demands of field service professionals.
